Is the dll in the correct VST folder? May have to add folder to Cantabile Options Tab.
Is it a 64 bit? Or it is a 32 bit wrapper used (JBridge)?
Is the correct version of Cantabile running with regards to 32 vs 64 bit?
If running Cantabile 64, got to have a wrapper for 32 bit plugs
If running Cantabile 32, may not run 64 bit plugs (never done this…)
My experience it to never have 64 and 32 components on the same machine. I always end up getting them confused.
Did you try browsing to the .dll file directly? If you can do that and it will load, that would tell you that your Cantabile is at least able to run the plugin. Take one question or if the picture.
Did you try a Full rescan of all your Plugins? Sometimes that heals mysterious wounds.
Another useful approach to debugging is as follows:
in Cantabile, select Tools-> Open settings folder
close Cantabile and load the file log.txt (from the opened settings folder) into a text editor
with the search function of the text editor, search for the name (or part of the name) of the plugin
If the name cannot be found, it probably means that the plugin is not in a folder which is considered by Cantabile. If it is found, maybe the log file will also report why it has not been loaded.
At least, this procedure has helped me a few times.
well…song and rack files are usually stored in a subfolder under your User folder (e.g. Users\Your_Name\Documents\Cantabile) and that folder is not deleted when Cantabile is uninstalled…so it should be already there when you reinstall it.
